36ZRO-B-1A-36PIN Female-waterproof ECU Connector

ZRO Series,Wire to Borad,Pitch 2.55,3 ROW,36P,Female,waterproof connector,PBT+15%GF Black

POSITIONS
8 – 35
SEALING RATING
IP67
CURRENT RATING
17 A
OPERATING TEMP
−40 → 125 °C

Request a Quote

Technical Data

Product type Features	Series	ZRO	Products Category	Wire to Board
	Male/Female	Female	Pitch(mm)	2.55
Configuration Features	Row	3	Number of Positions	36
	Applicablewire range	AVSS 0.5-0.75	Applicable Contacts	XT01064DPS-2/XT02064EPS-2
	Receptacle Style	-	Mating Connector	XW0206448MBA-A
Specifications and Features	Material-Plastic	PBT+15%GF	Flame retardancy	UL 94-V0
	Material-Metal	-	Plating	-
	Color	Black
Packaging Features	Packling	Bag	SPQ	-
Other Features	Waterproof	IP67	Original Factory Model	36ZRO-B-1A
Electrical Features	Rated current	3A	Rated voltage	-
	Operating Temperature	-40-120°C	Withstand Voltage	1000V/AC 1Mintue
	Contact resistance	10mΩ Max	Insulation resistance	100MΩ Min

feature

Engineered for Peak Performance

ZRO series of sealed connectors is a highly reliable, IP67 water-proof level, multi-pin connector with signal and power contacts.
Meanwhile it offers board side device connector, and cable side socket connector total connection solutions.
It can meet QC/T 1067.1 and USCAR-21 reliability standards. The connector is dedicated for harsh environmental usage. Various customer specific designs (e.g. different coding) are possible.
It can supply multi-way proposal for customer’s Choice (eg. 36 and 48 ways). The inflaming class is UL94-V0.
